Induction hob with integrated vapour extraction Silver
KMDA 5649 FL
620 mm | Individual cooking zones and flex cooking areaA contribution to recycling costs (PRF) of 5 EUR for large domestic appliances and 10 EUR for American Side by Side refrigeration is Included in the retail price. No fees apply to Vacuum Cleaners, Accessories, Hobs, Microwaves, Hoods or Coffee Machines.
Retail price includes 23% VAT.
Benefits
State-of-the-artCon@ctivity
Innovative convenience: the cooker hood reacts automatically to settings on the hob.
Safety functions
Our safety functions prevent any unwanted surprises.
Miele CleanCover
Protection and easy cleaning: the smooth concealed surface prevents contact with electrical components and motor.
Grease filters
Enjoy a spotless kitchen thanks to effective grease filters that can be easily cleaned in the dishwasher.
Flush-fit extractor
Flush and elegant: thanks to the discreet design, you can enjoy maximum design freedom in your kitchen.
Convenient additional functions
Numerous additional functions such as Stop & Go and the timer make life easier in the kitchen.
FlexZone
Unique space provision: the Miele FlexZones allow you to position large pots and pans behind each other.Con@ctivity
Innovative convenience: the cooker hood reacts automatically to settings on the hob.
ComfortSelect Plus
Compact and convenient: all cooking zones and the fan can be operated using a clear central numerical display.
Permanent pot recognition
Autom. activation of numerical keybank: When turned on, crockery that has been placed is recognised immediately.Downloads
Whether you are looking to replace an appliance or plan a new kitchen – you will find all the relevant installation drawings for your Miele appliance here. Please note that our products should only be installed and maintained by authorised experts. In the event of queries, please ring us for some no-obligation advice!
Descriptions
KMDA5649FL, KMDA5649FR, KMDA5649FL MattFinish - Installation variant 1 Basis
1) Square Plug&Play Adapter_A, 2) Square Plug&Play Adapter_B, 3) DFK-BVK 90, 4) DFK-V, 5) DFK-R 1000 POSTSCRIPT
Descriptions
KMDA5649FL, KMDA5649FR, KMDA5649FL MattFinish - Installation variant 2 Basis
1) Square Plug&Play Adapter_A, 2) Square Plug&Play Adapter_B, 3) DFK-BVK 90, 4) DFK-V, 5) DFK-R 1000 POSTSCRIPT
Descriptions
KMDA5649FL, KMDA5649FR, KMDA5649FL MattFinish - Installation variant 3 Basis
1) Square Plug&Play Adapter_A, 2) Square Plug&Play Adapter_B, 3) DFK-BVK 90, 4) DFK-V, 5) DFK-R 1000, 6) DFK-BH 90 POSTSCRIPT
Descriptions
KMDA5649FL, KMDA5649FR, KMDA5649FL MattFinish - Installation variant 4 Circulating air
The minimum width of the cabinet is 1350 mm., 1) Square Plug&Play Adapter_A, 2) Square Plug&Play Adapter_B, 3) DFK-BVK 90, 4) DFK-L, 5) DFK-R 1000, 6) DFK-V, 7) DFK-BH 90, 8) DUU 1500 POSTSCRIPT
Descriptions
KMDA5649FL, KMDA5649FR, KMDA5649FL MattFinish - Installation variant 5 Circulating air
The minimum width of the cabinet is 1350 mm., 1) Square Plug&Play Adapter_A, 2) Square Plug&Play Adapter_B, 3) DFK-BVK 90, 4) DFK-L, 5) DFK-R 1000, 6) DFK-V, 7) DFK-BH 90, 8) DUU 1500 POSTSCRIPT
Descriptions
KMDA5649FL, KMDA5649FR, KMDA5649FL MattFinish - Installation variant 6 Circulating air
The minimum width of the cabinet is 935 mm., 1) Square Plug&Play Adapter_A, 2) Square Plug&Play Adapter_B, 3) DFK-BVK 90, 4) DFK-L, 5) DFK-R 1000, 6) DFK-V, 7) DUU 1500 POSTSCRIPT
Descriptions
KMDA5649FL, KMDA5649FR, KMDA5649FL MattFinish - Installation variant 13 Circulating air
The minimum width of the cabinet is 1125 mm., 1) Square Plug&Play Adapter_A, 2) Square Plug&Play Adapter_B, 3) DFK-BVK 90, 4) DFK-L, 5) DFK-R 1000, 6) DFK-V, 7) DFK-BH 90, 8) DUU 1500 POSTSCRIPT
Descriptions
KMDA5649FL, KMDA5649FR, KMDA5649FL MattFinish - Installation variant 14 Circulating air
The minimum width of the cabinet is 900 mm., 1) Square Plug&Play Adapter_A, 2) Square Plug&Play Adapter_B, 3) DFK-BVK 90, 4) DFK-L, 5) DFK-R 1000, 6) DFK-V, 7) DFK-BH 90, 8) DUU 1500 POSTSCRIPT
Descriptions
KMDA5649FL, KMDA5649FR, KMDA5649FL MattFinish - Installation variant 9 Exhaust air
1) Square Plug&Play Adapter_A, 2) Square Plug&Play Adapter_B, 3) DFK-BVK 90, 4) DFK-V, 5) DFK-R 1000, 6) DFK-BH 90, 7) DFK-A, 8) DMK 150-1 POSTSCRIPT
Descriptions
KMDA5649FL, KMDA5649FR, KMDA5649FL MattFinish - Installation variant 10 Exhaust air
1) Square Plug&Play Adapter_A, 2) Square Plug&Play Adapter_B, 3) DFK-BVK 90, 4) DFK-V, 5) DFK-R 1000, 6) DMK 150-1, 7) DFK-AK 90 POSTSCRIPT
Descriptions
KMDA5649FL, KMDA5649FR, KMDA5649FL MattFinish - Installation variant 12 Exhaust air
1) Square Plug&Play Adapter_A, 2) Square Plug&Play Adapter_B, 3) DFK-BVK 90, 4) DFK-V, 5) DFK-R 1000, 6) DFK-BH 90, 7) DFK-A, 8) DMK 150-1 POSTSCRIPT
Descriptions
①When routing the exhaust air between the cabinet wall and an adjacent room wall or an adjacent piece of furniture, a minimum distance of 25 mm must be observed. ②The removable collection tray and the cleaning flaps must be accessible after installation. ③The cross-section of the vent opening must be at least 425 cm². ④Distance from the front of the lower box to the end of the plug & play adapter
KMDA5649FL, KMDA5649FL MattFinish - Side view lying on top, Plug&Play PDF
Descriptions
①When routing the exhaust air between the cabinet wall and an adjacent room wall or an adjacent piece of furniture, a minimum distance of 25 mm must be observed. ②The removable collection tray and the cleaning flaps must be accessible after installation. ③The cross-section of the vent opening must be at least 425 cm². ④Distance from the front of the lower box to the end of the plug & play adapter.
KMDA5649FL, KMDA5649FL MattFinish - Side view flush, Plug&Play PDF
Descriptions
①When routing the exhaust air between the cabinet wall and an adjacent room wall or an adjacent piece of furniture, a minimum distance of 25 mm must be observed. ②The removable collection tray and the cleaning flaps must be accessible after installation. ③The cross-section of the vent opening must be at least 425 cm². ④Distance from the front of the lower box to the end of the plug & play adapter.
KMDA5649FL, KMDA5649FL MattFinish - Side view flush+X, Plug&Play PDF
Descriptions
①When routing the exhaust air between the cabinet wall and an adjacent room wall or an adjacent piece of furniture, a minimum distance of 25 mm must be observed. ②The removable collection tray and the cleaning flaps must be accessible after installation. ③The cross-section of the vent opening must be at least 425 cm². ④Distance from the front of the lower box to the end of the plug & play adapter.
KMDA5649FL, KMDA5649FL MattFinish - Side view lying on top+X, Plug&Play PDF
Descriptions
①The rear wall of the cabinet must be removable for servicing. A minimum distance of 110 mm must be maintained for routing the exhaust air duct between the cabinet wall and an adjacent room wall or furniture. ②The removable collection tray and the cleaning flaps must be accessible after installation.
KMDA5649FL, KMDA5649FL MattFinish - Side view flush PDF
Descriptions
①The rear wall of the cabinet must be removable for servicing. A minimum distance of 110 mm must be maintained for routing the exhaust air duct between the cabinet wall and an adjacent room wall or furniture. ②The removable collection tray and the cleaning flaps must be accessible after installation. x Dimension by which the worktop depth is greater than 600 mm.
KMDA5649FL, KMDA5649FL MattFinish - Side view flush+X PDF
Descriptions
①The rear wall of the cabinet must be removable for servicing. A minimum distance of 110 mm must be maintained for routing the exhaust air duct between the cabinet wall and an adjacent room wall or furniture. ②The removable collection tray and the cleaning flaps must be accessible after installation.
KMDA5649FL, KMDA5649FL MattFinish - Side view lying on top PDF
Descriptions
①The rear wall of the cabinet must be removable for servicing. A minimum distance of 110 mm must be maintained for routing the exhaust air duct between the cabinet wall and an adjacent room wall or furniture. ②The removable collection tray and the cleaning flaps must be accessible after installation. x Dimension by which the worktop depth is greater than 600 mm.
KMDA5649FL, KMDA5649FL MattFinish - Side view lying on top+X PDF
Descriptions
1) Front 2) Removable drip tray 3) Cleaning flaps 4) Mains connection box with mains connection cable, L = 1.080 mm 5) Worktop thickness Exhaust air and guided recirculation mode: ≥10 mm Plug&Play operation: ≥10 mm - ≤40 mm
KMDA5649FL, KMDA5649FL MattFinish - Installation lying on top PDF
Descriptions
1) Front 2) Removable drip tray 3) Cleaning flaps 4) Mains connection box with mains connection cable, L = 1.080 mm 5) Step milling natural stone worktop 6) Wooden strip 12 mm (not included in delivery) 7) Worktop thickness Exhaust air and guided recirculation mode: ≥10 mm Plug&play operation: ≥10 mm - ≤40 mm
KMDA5649FL, KMDA5649FL MattFinish - Installation flush PDF
Descriptions
KMDA5649FL, KMDA5649FR, KMDA5649FL MattFinish, Drilling Template, Flush Installation, Page 1
DownloadPDF
Descriptions
KMDA5649FL, KMDA5649FR, KMDA5649FL MattFinish, Drilling Template, surface mounted Installation, Page 2
DownloadPDF
