  • Miele - DAE 1530 Stainless steel – Cooker hoods - 1
  • Miele - DAE 1530 Stainless steel – Cooker hoods - 2
  • Miele - DAE 1530 Stainless steel – Cooker hoods - 3
  • Miele - DAE 1530 Stainless steel – Cooker hoods - 4
Extractor unitSilver

DAE 1530 Stainless steel

with EasySwitch controls for convenient operation
Colour:Stainless steel
sale price€499.99
12
A contribution to recycling costs (PRF) of 5 EUR for large domestic appliances and 10 EUR for American Side by Side refrigeration is Included in the retail price. No fees apply to Vacuum Cleaners, Accessories, Hobs, Microwaves, Hoods or Coffee Machines.
Retail price includes 23% VAT.


Product details

  • Customised kitchen design - fully integrated in 532 mm width
  • Powerful – at the highest level
  • LED strip for uniform lighting
  • Efficient filtration-
    10-ply stainless-steel grease filter
  • Safe and easy to clean -
    Miele CleanCover
  • View manufacturer details:
  • Safety information

Product data sheet

Model identifier
DAE 1530
Manufacturer material number
12760960
EAN number
4002516879633
Marketing class
Silver
Integrated extractor
Type of air guide
Can be retrofitted
Recirculation conversion kit (order separately)
DUU 150,DUU 151
Active charcoal filter (order separately)
DKF 32-P
Colour
Stainless steel
Electronic controls
Touch-on-glass controls
Controls
EasySwitch
Power levels (number without Booster level)
3
Booster levels
1
Easy-to-clean canopy interior – CleanCover
Energy efficiency class (A+++ to D)
B
Annual energy consumption in kWh/year
72.2
Fluid dynamic efficiency class
B
Lighting efficiency class
A
Grease filtering efficiency class
B
Easy-to-clean canopy interior – CleanCover
Number of dishwasher-safe stainless steel grease filters (10-ply)
1
Number x W
1 x 3,2 W
Light intensity in Lx
360 lx
Colour temperature in K
3500 Kelvin
Number of fans
1
Dual-action blower
Air throughput in Level 1 (m³/h) according to EN 61591
215
Air throughput in Level 2 (m³/h) according to EN 61591
315
Air throughput in Level 3 (m³/h) according to EN 61591
415
Air throughput in Booster level 1 (m³/h) according to EN 61591
675
Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-3
45
Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-3
48
Sound power in Level 3 (dB(A) re 1 pW) according to EN 60704-3
53
Sound power in Booster level 1 (dB(A) re 1 pW) acc. to EN 60704-3
65
Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-13
30
Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-13
34
Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-13
39
Sound pressure in Booster level 1 (dB(A) re 20 µPa) acc. to EN 60704-2-13
51
Air throughput in Level 1 (m³/h) according to EN 61591
200
Air throughput in Level 2 (m³/h) according to EN 61591
295
Air throughput in Level 3 (m³/h) according to EN 61591
395
Air throughput in Booster level 1 (m³/h) according to EN 61591
630
Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-3
46
Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-3
53
Sound power in Level 3 (dB(A) re 1 pW) according to EN 60704-3
59
Sound power in Booster level 1 (dB(A) re 1 pW) acc. to EN 60704-3
71
Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-13
32
Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-13
39
Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-13
45
Sound pressure in Booster level 1 (dB(A) re 20 µPa) acc. to EN 60704-2-13
57
Safety shut-off
Canopy dimensions (W x H x D) in mm
532 x 50 x 372
Canopy width in in. (mm)
532
Canopy height in in. (mm)
50
Depth of hood canopy in in. (mm)
372
Minimum height above electric hobs in mm
450
Minimum safety distance above gas hobs (max. 12.6 kW total power, burner ≤ 4.5 kW) in mm
650
Net weight in kg
9
Length of supply lead in m
1.5
Standard plug fitted
Total rated load in kW
0.203
Voltage in V
230
Fuse rating in A
10
Frequency in Hz
50
Number of phases
1
Extraction ducting connection at top
Diameter of extraction ducting connection in mm
150
Non-return flap
EAN
4002516879633

What's included

Non-return flap
  • Easy to use and effective against grease
    Easy to use and effective against grease

    Stainless steel grease filters (10-layer)

    Looks great and does a good job: effective grease filtering and easy cleaning in a dishwasher.

  • Convenience and safety in detail
    Convenience and safety in detail

    CleanCover

    Protection and easy cleaning: the smooth concealed surface prevents contact with electrical components and motor.

Safety

Always on the safe side
Always on the safe side

Safety switch-off

Sensible, even in case of operating errors: the cooker hood switches off automatically after 10 hours.

Features

Easy to use and effective against grease
Easy to use and effective against grease

Stainless steel grease filters (10-layer)

Looks great and does a good job: effective grease filtering and easy cleaning in a dishwasher.
Convenience and safety in detail
Convenience and safety in detail

CleanCover

Protection and easy cleaning: the smooth concealed surface prevents contact with electrical components and motor.

Downloads

Installation plan
PDF
Download
Operating instructions/Installation instructions
PDF
Download
Product sheet
PDF
Download
Warranty conditions
PDF
Download
dwg
ZIP
Download
fbx
ZIP
Download
ifc
ZIP
Download
rfa
ZIP
Download
rvt
ZIP
Download
Energy label
PDF
Download
Energy label
PNG
Download
Energy label
PDF
Download

Whether you are looking to replace an appliance or plan a new kitchen – you will find all the relevant installation drawings for your Miele appliance here. Please note that our products should only be installed and maintained by authorised experts. In the event of queries, please ring us for some no-obligation advice!

https://media.miele.com/dam/03510192-1252-4ff0-b4f2-b3bb00806341/20000216049_HighresDigitalRGB.png
Descriptions
DAE1530, DAE1535 Installation drawing
1) Exhaust air connection alternatively to the rear., Exhaust air connection Ø 150 mm., Further detailed dimensions can be found in the operating instructions!
POSTSCRIPT
Download
  • 1.A contribution to recycling costs (PRF) of 5 EUR for large domestic appliances and 10 EUR for American Side by Side refrigeration is Included in the retail price. No fees apply to Vacuum Cleaners, Accessories, Hobs, Microwaves, Hoods or Coffee Machines.
  • 2.Retail price includes 23% VAT.

We reserve the right to make technical changes; we assume no liability for the accuracy of the information provided.
