Wall mounted cooker hood

DAH 2960 Escala Obsidian black

with Con@ctivity and smart touch controls for convenience


Colour:Obsidian black

sale price€1,399.99
A contribution to recycling costs (PRF) of 5 EUR for large domestic appliances and 10 EUR for American Side by Side refrigeration is Included in the retail price. No fees apply to Vacuum Cleaners, Accessories, Hobs, Microwaves, Hoods or Coffee Machines.
Retail price includes 23% VAT.



Product details

  • Lots of headroom – 898 mm 898 mm wide glass canopy
  • Unique user convenience –Con@ctivity
  • Efficient filtration-10-ply stainless-steel grease filter
  • Perfect match – glass panel and canopy in the same colour
  • Suitable for every home - for extraction or recirculation

Product data sheet

Wall mounted cooker hood
Type of air guideCan be retrofitted
Active charcoal filter (order separately)DKF 29 charcoal filter
ColourObsidian black
Edge extraction
Miele@home
Automatic function Con@ctivity
Electronic controls
ControlsComfortControl
ON/OFF switch
Power levels (number without Booster level)3
Booster levels1
Easy-to-clean canopy interior – CleanCover
Energy efficiency class (A+++ to D)B
Annual energy consumption in kWh/year72.3
Fluid dynamic efficiency classB
Lighting efficiency classA
Grease filtering efficiency classD
Easy-to-clean canopy interior – CleanCover
Number of dishwasher-safe stainless steel grease filters (10-ply)2
LED
Number x W1 x 3,2 W
Light intensity in Lx300 lx
Colour temperature in K3500 Kelvin
Dual-action blower
AC motor
Air throughput in Level 1 (m³/h) according to EN 61591215
Air throughput in Level 2 (m³/h) according to EN 61591315
Air throughput in Level 3 (m³/h) according to EN 61591415
Air throughput in booster level 1 (m³/h)675
Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-341
Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-347
Sound power in Level 3 (dB(A) re 1 pW) according to EN 60704-353
Sound power in Booster level 1 (dB(A) re 1 pW) acc. to EN 60704-365
Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-1327
Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-1333
Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-1339
Sound pressure in Booster level 1 (dB(A) re 20 µPa) acc. to EN 60704-2-1351
Air throughput in Level 1 (m³/h) according to EN 61591190
Air throughput in Level 2 (m³/h) according to EN 61591280
Air throughput in Level 3 (m³/h) according to EN 61591380
Air throughput in Booster level 1 (m³/h) according to EN 61591575
Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-347
Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-354
Sound power in Level 3 (dB(A) re 1 pW) according to EN 60704-360
Sound power in Booster level 1 (dB(A) re 1 pW) acc. to EN 60704-371
Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-1333
Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-1340
Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-1346
Sound pressure in Booster level 1 (dB(A) re 20 µPa) acc. to EN 60704-2-1357
Safety shut-off
Single-ply safety glass (ESG)
Overall height for vented and external in in. (mm)830
Overall height for extraction mode and external mode cooker hoods in mm1210
Overall height for recirculation in in. (mm)443
Overall height for recirculation mode cooker hoods in mm443
Canopy width in in. (mm)898
Canopy height in in. (mm)443
Depth of hood canopy in in. (mm)388
Minimum height above electric hobs in mm450
Minimum safety distance above gas hobs (max. 12.6 kW total power, burner ≤ 4.5 kW) in mm650
Net weight in kg18
Length of supply lead in m1.3
Standard plug fitted
Total rated load in kW0.203
Voltage in V230
Fuse rating in A10
Frequency in Hz50
Number of phases1
Extraction ducting connection at top
Extraction connection at top and rear
Diameter of extraction ducting connection in mm150
Non-return flap
EAN4002516801504

What's included

Non-return flap

Safety

Always on the safe side
Safety switch-off

Sensible, even in case of operating errors: the cooker hood switches off automatically after 10 hours.


Features

Easy to use and effective against grease
Stainless steel grease filters (10-layer)

Looks great and does a good job: effective grease filtering and easy cleaning in a dishwasher.


Convenience and safety in detail
Miele CleanCover

Protection and easy cleaning: the smooth concealed surface prevents contact with electrical components and motor.


Decorative panels instead of metal grease filters
Edge extraction

Efficient and beautiful: With edge extraction grease filters are concealed by a stainless steel or glass panel.


User convenience

Automatic operation for intelligent fan control
Con@ctivity

Innovative convenience: the cooker hood reacts automatically to settings on the hob.


Downloads

Operating instructions/Installation instructions
PDF
Downloads
Warranty conditions
PDF
Downloads
Product sheet
PDF
Downloads
Installation plan
PDF
Downloads
ifc
ZIP
Downloads
fbx
ZIP
Downloads
dwg
ZIP
Downloads
rvt
ZIP
Downloads
rfa
ZIP
Downloads
Product fiche
PDF
Downloads
Energy label
PDF
Downloads
Energy label
PNG
Downloads
Energy label
Downloads

Whether you are looking to replace an appliance or plan a new kitchen – you will find all the relevant installation drawings for your Miele appliance here. Please note that our products should only be installed and maintained by authorised experts. In the event of queries, please ring us for some no-obligation advice!

https://media.miele.com/images/2000020/200002057/20000205751.png
Descriptions
DAH2960 Installation drawings
1) Break-through if the mains connection is not made with a mains plug, but with a fixed connection., 2) Exhaust air opening ø 200 mm, so that the exhaust air line can be moved in the wall. Exhaust air connection ø 150 mm to the top or alternatively to the rear., 3) Air outlet for recirculated air. The distance to the ceiling or furniture mounted above the unit should be at least 300 mm.
