Built-under dishwasher
PFD 101 U
For large amounts of crockery in households, office tea rooms and utility areas.Product details
- Wash performance: 13 place settings in just 36 min.5,
- Maximum final rinse temperature of 82 °C
- 13 % less energy consumption6,
- Everything completely dry –AutoOpen assisted dryingLoading...
- Flexible loading of load items for the best cleaning resultsLoading...
- View manufacturer details:
- You will find more information about product data and your rights under the EU Data Acthere
- Safety information
Product data sheet
- Construction typeLoading...
- Built-under dishwasher
- Range
- ProfiLine
- Wash systemLoading...
- Fresh water front loader
- Number of levels
- 2
- Front
- Brilliant white
- Side panels
- Galvanised
- Fascia color
- CleanSteel
- Suitable for guesthousesLoading...
- Suitable for universities and schoolsLoading...
- Suitable for officesLoading...
- Suitable for domestic useLoading...
- Suitable for small businessesLoading...
- Suitable for sports clubsLoading...
- Tested virucidal efficacyLoading...
- Proven hygieneLoading...
- Circulation pump Qmax in l/min.
- 75
- Shortest programme duration in min.
- 36Loading...
- Maximum final rinse temperature in °C
- 82
- Cleaning performance, place settings/cycle
- 13
- Service life in wash cycles
- 12500Loading...
- Network-enabled with Miele MOVELoading...
- Loading...
- Control systemLoading...
- Electronic controls
- Programme selection
- Programme selector buttons
- Max. delay start in h
- 24
- Time left display
- Dishwashing programmes [number]
- 8
- Programme sequence indicator
- Choice of display languageLoading...
- Check filter indicatorLoading...
- Electrical connection
- AC 230V 50HZ
- Heater rating in kW
- 1.900
- Total connected load in kW
- 2.100
- Fuse rating in A
- 13
- Length of mains connection cable in m
- 1.70Loading...
- Provided with plugLoading...
- Electrical connection
- AC 230V 50HZ
- Heater rating in kW
- 6.100
- Total connected load in kW
- 6.300
- Fuse rating in A
- 32
- Cold or hot water [number]
- 1
- Required flow pressure in bar
- 1.00 - 10.00
- Drain pump [DN]
- 22
- Drain pump head height from floor level, max. in c
- 100
- Integrated water softenerLoading...
- Maximum water hardness in mmol/l
- 6.50Loading...
- Water protection systemLoading...
- Waterproof system
- Length of water inlet hose in cm
- 150
- Length of water drain hose in cm
- 150
- External dimensions, height in mm
- 805Loading...
- External dimensions, net width in mm
- 598
- External dimensions, net depth in mm
- 570
- External dimensions, gross height in mm
- 970Loading...
- External dimensions, gross width in mm
- 670Loading...
- External dimensions, gross depth in mm
- 690Loading...
- Usable space in wash cabinet, height in mm
- 540
- Usable space in wash cabinet, width in mm
- 510
- Usable space in wash cabinet, depth of upper baske
- 450
- Usable space in wash cabinet, depth of lower basket in mm
- 450
- In-feed height above floor in mm
- 210
- Required niche width in mm
- 600
- Net weight [kg]
- 47
- Gross weight in kg
- 55Loading...
- Maximum floor load in N/m²
- 1000Loading...
- Emissions – sound pressure at workplace
- 33 dB(A) re 20 µPaLoading...
- UniversalLoading...
- ShortLoading...
- HygieneLoading...
- Cold/Pre-wash
- GlassesLoading...
- PlasticsLoading...
- Eco
- IntensiveLoading...
- ExtraComfort P basketsLoading...
- Flexible FlexLine basket designLoading...
- FlexCare glass holder [number]
- 2
- FlexCare cup rack [number]
- 1
- Cutlery basketLoading...
- Height-adjustable upper basketLoading...
- Combinable with APFD 210 bottle basketLoading...
- DryingLoading...
- [ "Active condensation drying", "Extra drying", "AutoOpen assisted drying" ]
- Adjustable final rinse temperature
- WiFiLoading...
- AutoClose
- Loading...
- 1 combi dispenser in the door for powder cleaning agent and rinsing agent
- EcoFeedbackLoading...
- Safety lock
- Brilliant GlassCareLoading...
- Wash cabinet made from high-quality stai
- Optical interface
- SmartStartLoading...
- FlexiTimer with EcoStartLoading...
- Load size of the ECO programme in place settings
- 13
- Energy efficiency class (A–G)
- E
- Energy consumption of the ECO program per 100 cycles
- 93
- Water consumption of the ECO programme per cycle in l
- 12
- Acoustic airborne noise emission class (A–D)
- C
- Acoustic airborne noise emission in dB(A) re 1 pW
- 46
- Programme running time of the ECO programme in min
- 250
- External dispensing module for liquid cleaning agentLoading...
- CE
- Complies with Machinery Directive 2006/42/EC
- VDE
- EMC radio suppressed
- DIN EN 17735
- EN 1717
- Regulation 4 compliant
- UKCA
- EAN
- 4002516367031
- *If the machine can be converted to a different voltage option, additional possible rated load values for electrical connection can be found here. This conversion can be carried out by Miele Customer Service for a fee.
Dishwashing professionals for daily dish mountainsFor businesses
These dishwashers are ideally suited for all areas which deal with large amounts of crockery.
For dry crockery in next to no timeAutoOpen assisted drying
Completely dry: The dishwasher door opens automatically at the end of the programme.
- Maximum hygiene assurance
Fresh water system
Constantly high cleaning performance and hygiene thanks to repeated water changes.
Long service lifeQuality you can rely on
Durability: Miele Professional dishwashers are tested for a long service life.
Effective against viruses – scientifically provenProven hygiene
Our dishwashers in the PFD 10x series remove more than 99.9 %2, of all viruses (including coronaviruses).
Machine data can be accessed at all timesNetwork-enabled with Miele MOVE
All terminal devices can access machine data at all times thanks to networking with Miele MOVE.
Connectivity

Network-enabled with Miele MOVE
All terminal devices can access machine data at all times thanks to networking with Miele MOVE.
Future-proof networking via WiFi
Fully informed with a high-performance network connection.Efficiency

Connection for detergent dispenser module
An optional dispenser module can be connected for convenient and economical use of liquid agents.
Low consumption values
Economical and efficient: Miele Professional dishwashers stand out with low consumption values.
Integrated water softener
The built-in softener ensures the optimum hardness level of the water for perfect dishwashing results.
Highly effective filter system
Outstanding dishwashing results and reliability are largely due to the highly effective filter system.
SmartStart
Practical: this function sets the machine to work automatically when electricity is at its cheapest.
FlexiTimer with EcoStart
Clever: with EcoStart, the dishwasher automatically selects the cheapest electricity tariff every time.
EcoFeedback
Economical: when a programme is selected, estimated water consumption values are displayed.Hygiene
Fresh water system
Constantly high cleaning performance and hygiene thanks to repeated water changes.
Proven hygiene
Our dishwashers in the PFD 10x series remove more than 99.9 %2, of all viruses (including coronaviruses).
Proven hygiene
Our dishwashers in the PFD 10x series remove 99.999 %3, of most bacteria.Performance

For businesses
These dishwashers are ideally suited for all areas which deal with large amounts of crockery.
AutoOpen assisted drying
Completely dry: The dishwasher door opens automatically at the end of the programme.
Perfect integration into kitchen runs and worktops
Perfect appearance thanks to dishwashers that can be built-under.
Brilliant GlassCare
Gentle and delicate: Brilliant GlassCare cleans your glassware with care.Quality

Conforms to Machinery Directive
Miele commercial machines comply with applicable safety regulations.
Powerful heater pump
For maximum cleaning performance, every dishwasher is equipped with a powerful heater pump.
Water protection guarantee4,
Peace of mind: Miele will bear the cost for damage resulting from a defect in the water system.
Quality you can rely on
Durability: Miele Professional dishwashers are tested for a long service life.User convenience

Delay start and countdown indicator
For maximum flexibility, a delay start time of up to 24 hours can be selected.
AutoClose
A light touch is all it takes: With AutoClose, the door closes by itself.
Selectable display languages
All-rounder: you can choose the language for the display so that you fully understand everything.
Provided with plug
Plug and play: with its plug attached ex works, all you need is a socket to connect it.Basket design

Cutlery basket
Extremely versatile: The cutlery basket fits in any position over the front spikes in the lower basket.
Height-adjustable upper basket
The height of the upper basket can be adjusted to suit the items being cleaned.
FlexLine baskets
Flexibility creates convenience: easy adjustment and flexible loading for the best cleaning results.
Practical bottle basket
Bottles can be reliably cleaned inside using the APFD 210 basket, which is available to purchase separately.Downloads
Hygiene Certificate
DownloadPDF
- 1.Retail price includes 23% VAT.
- 2.A description of the relevant methodology can be found at the following link:
a href="https://www.miele.com/media/ex/com/Professional/Pruefberichte_Virussiegel/PFD10x_Viruswirksamkeit_Testkriterien_Virus_effectiveness_test_criteria_2021-11-25.pdf" http://miele.com/PFD10x-c /a - 3.The hygiene certificate can be found
a href="https://www.miele.com/media/ex/com/Professional/Pruefberichte_Virussiegel/Zertifikat_gepruefte_Hygiene-kombiniert.pdf" here /a . - 4.For details please refer to our warranty terms and conditions for water protection.
- 5.Programme running time without drying. The values quoted may vary depending on the on-site conditions (water inlet temperature/electrical connection).
- 6.Based on the ECO programme, compared to predecessor.
We reserve the right to make technical changes; we assume no liability for the accuracy of the information provided.
