T1 heat-pump dryer: with DryCare 40 and SilenceDrum for quiet drying with maximum convenience.
What’s included
- Fragrance flacon
- Voucher for a second fragrance flacon
TEH785WP EcoSpeed&9kg
T1 heat-pump dryer: with DryCare 40 and SilenceDrum for quiet drying with maximum convenience.
Optional Premium Services
You can select the following services for this product in your basket:
Freestanding Installation (€50.00)
Stacked Laundry Installation (€80.00)
WEEE Collection (€0.00)
- Subject to technical changes; no liability accepted for the accuracy of the information given. See General Terms and Conditions in footer for additional details.
T1 heat-pump dryer: with DryCare 40 and SilenceDrum for quiet drying with maximum convenience.
What’s included
- Fragrance flacon
- Voucher for a second fragrance flacon
Your advantages
Energy efficiency
Environmentally friendly tumble drying
Best Miele performance: with optimum energy efficiency, you can achieve maximum efficiency and excellent results.
Exclusive to Miele
EcoDry technology
Short programme running times, low consumption
More time and money for the important things in life thanks to short running times and low energy consumption.
Exclusive to Miele
Domestic appliance networking with Miele@home*
Cleverly networked
Make your life smart: thanks to Miele@home, you can cleverly network your domestic appliances – for more options.
DryCare 40
Completely new options for tumble drying
Gentle fabric care: DryCare 40 dries almost anything that can be washed at 40 °C*. This saves time.
Exclusive to Miele
FragranceDos fragrance system*
A fresh fragrance for your laundry
Freshness for all the senses: the Miele fragrance flacon makes your laundry smell wonderful.
Features depend on model – images are only examples and used for explanation purposes
Safety (1)
Highest condensation efficiency
Optimum protection for your home
Best protection for room and furniture: 50% less moisture loss than required for condensation efficiency class A.
Efficiency and sustainability (5)
Energy efficiency
Environmentally friendly tumble drying
Best Miele performance: with optimum energy efficiency, you can achieve maximum efficiency and excellent results.
ProfiEco motor*
Economical, powerful and maintenance-free
Powerful and economical: our ProfiEco motors with inverter drive ensure wear-free, quiet, energy-saving operation.
Maintenance-free heat exchanger
Constantly low energy consumption
Save time and energy: a filter protects the heat exchanger so it no longer requires cleaning.
Exclusive to Miele
EcoDry technology
Short programme running times, low consumption
More time and money for the important things in life thanks to short running times and low energy consumption.
EcoSpeed
Save time and protect the environment
Double bonus: thanks to EcoSpeed, you can dry your laundry over 20 minutes faster* with optimum energy efficiency
Drying programs (6)
Shirts
Business as usual
Prevents creasing: reduces creasing and simplifies the ironing of shirts and blouses significantly.
Delicates
Optimum care of synthetic fibres
Takes care of synthetic fibres: these look good & stay in shape for longer when dried with this special programme.
Finish Woollens
Most gentle treatment of your favourite garments
Beautifully fluffy: Delicate wool fabrics are handled particularly gently, maintaining their quality.
Express
Drying in the shortest time
Sometimes things have to be done fast: so small laundry loads are dried quickly and can be used again.
Proofing
Equip textiles with functions
Best possible effect: Thermally fixing ensures optimum water-repellent properties.
Bed linen
Bed linen
Best results: uniform drying of large items of textiles.
Quality (2)
Exclusive to Miele
Exclusive to Miele
SilenceDrum
Particularly quiet drying
Significantly quieter: the SilenceDrum reduces rattling noises caused by items such as buttons in the drum.
User convenience (4)
Integrated condensed water drainage
Convenient water drainage
Emptying not necessary: the condensation can be drained off via a hose directly into the sink or a U-tube.
AddLoad
Add large & small items even after programme start
Maximum convenience: you can easily add or remove laundry items even after the programme has started.
Domestic appliance networking with Miele@home*
Cleverly networked
Make your life smart: thanks to Miele@home, you can cleverly network your domestic appliances – for more options.
Wash2Dry*
The cleverly networked laundry care team
Hand in hand: your tumble dryer automatically uses the same programme as your washing machine.
Gentle laundry care (3)
Anti-crease action
Looser laundry after drying
Practically crease-free: the laundry is loosened regularly after the programme has finished, preventing creasing.
Heat-pump technology
Protects the environment and your clothes
Environmentally friendly and gentle: drying at low temperatures protects both the environment and your clothes.
DryCare 40
Completely new options for tumble drying
Gentle fabric care: DryCare 40 dries almost anything that can be washed at 40 °C*. This saves time.
Drying results (3)
Exclusive to Miele
PerfectDry precision drying
Gentle laundry care to perfection
Soft and fluffy laundry: PerfectDry ensures your laundry is never too damp or too dry.
HygieneDry
Effective against bacteria
Hygienically clean: HygieneDry can be relied upon to remove 99.99 %* of bacteria.
Exclusive to Miele
FragranceDos fragrance system*
A fresh fragrance for your laundry
Freshness for all the senses: the Miele fragrance flacon makes your laundry smell wonderful.
Product data sheet
Construction type
| Suitable for stacking | • |
| Side-by-side | • |
| Slot-in | • |
| Can be built-under | • |
| Door hinge | left |
Model
| Product brand | T1 Chrome Edition |
| Heat pump dryer | • |
Design
| Appliance colour | Lotus white |
| Control panel colour | Lotus white |
| Rotary selector colour | Lotus White / Chrome ring |
| Control panel version | Straight |
| Control type | Rotary control |
| Display | DirectSensor white, 7 segment |
Drying results
| PerfectDry precision drying | • |
| FragranceDos² fragrance system | • |
| Intelligent drum reversal | • |
| Proven hygiene | • |
| Proven virus hygiene | • |
Gentle laundry care
| SilenceDrum | • |
| Load in kg | 9 |
User convenience
| Networking with Miele@home | • |
| Wash2Dry | • |
| Delay start up to 24 hours | • |
| Time left display | • |
| Drum lighting | LED |
| Acoustics package for the lowest sound emissions | • |
| Condensate container | • |
| Integrated condensed water drainage | • |
| AddLoad | • |
Efficiency and sustainability
| Energy efficiency class (A+++ - D) | A+++ |
| Annual energy consumption in kWh | 185 |
| Duration in minutes in the standard programme | 184 |
| Noise in the Cottons programme with full load in db(A) re 1 pW | 64 |
| Condensation efficiency class | A |
| Energy consumption in kWh in the Cottons Normal dry standard programme with a full load | 1.55 |
| EcoDry technology | • |
| Maintenance-free heat exchanger | • |
| ProfiEco motor | • |
| EcoSpeed | • |
Drying programmes
| Cottons (coloureds) | • |
| Minimum iron | • |
| Delicates | • |
| Shirts | • |
| Woollens handcare | • |
| Express | • |
| Proofing | • |
| Bed linen | • |
| Warm air/DryFresh | • |
Drying extras
| Anti-crease | • |
| Buzzer | • |
| DryCare 40 | • |
Quality
| Soft ribs | • |
Safety
| PIN-Code | • |
| Empty out container indicator | • |
| Clean filter indication | • |
| Optical interface | • |
Technical data
| Dimensions in mm (width) | 596 |
| Dimensions in mm (height) | 850 |
| Dimensions in mm (depth) | 636 |
| Appliance depth in mm with opened door | 1054 |
| Weight in kg | 57 |
| Total rated load in kW | 1.10 |
| Voltage in V | 220.00-240.00 |
| Fuse rating in A | 13 |
| Frequency in Hz | 50 |
| Length of supply lead in m | 2 |
| Hermetically sealed | • |
| Type of coolant | R290 |
| Refrigerant quantity in kg | 0.14 |
| Refrigerant global warming potential in CO₂ e | 3 |
| Appliance global warming potential in CO₂ e | 0.42 |
| Replacing lamps | Service |
Accessories included
| Fragrance flacon | • |
| Voucher for a second fragrance flacon | • |
Supplementary products and accessories
Downloads, CAD & Apps
- Warranty conditionsPDF
- User manualPDF
- EU declaration of conformityPDF
- Product sheetPDF
- rfaZIP
- dwgZIP
- fbxZIP
- ifcZIP
- rvtZIP
- Product fichePDF
- Energy labelPNG
- Energy labelPDF
- Energy label
Whether you are looking to replace an appliance or plan a new kitchen – you will find all the relevant installation drawings for your Miele appliance here. Please note that our products should only be installed and maintained by authorised experts. In the event of queries, please ring us for some no-obligation advice!
Descriptions
T1 drawing, slanted facia or straight facia, measures in mm
Descriptions
T1 installation drawing, slanted facia or straight facia, measures in mm
Descriptions
T1 drawing, slanted facia or straight facia, with porthole, measures in mm
Descriptions
T1 drawing, slanted facia or straight facia, measures in mm
Monitor your Miele appliances while you are on the go.
With the Miele app for your smartphone or tablet you can now connect all your Miele appliances and benefit from its smart home features.
1. A contribution to recycling costs (PRF) of 5 EUR for large domestic appliances and 10 EUR for American Side by Side refrigeration is Included in the retail price. No fees apply to Vacuum Cleaners, Accessories, Hobs, Microwaves, Hoods or Coffee Machines.
- 3.Not suitable for woollens or silks.
- 4.Patent: EP 2 431 516
- 5.Tested for Bacillus subtilis and Saccharomyces cerevisiae bacteria in the HygieneDry drying level with half load. A description of the relevant methodology can be found at the following link:
a href="https://www.miele.com/media/ex/com/Testkriterien_Hygiene-Siegel_T1.pdf" miele.de/testkriterien-trockner /a - 6.During the development phase of the T1 tumble dryer series, Miele tested models and core components in 5000 drying cycles (= 5 drying cycles per week for 50 weeks per year) in various programmes. More: miele.com/20years
- 7.Compared to Miele tumble dryers without EcoSpeed with the same load size and energy efficiency class. Tested in the Cottons programme with a full load size.
- 8.Patent: EP 2 840 679
- 9.For this function to work, the tumble dryer and washing machine must be registered in the in-house network and/or in the app.
- 10.Additional digital offer from Miele & Cie. KG. All smart applications are made possible with the Miele@home system. The range of functions can vary depending on the model and the country.
- 11.Patent: EP 2 107 155
- Subject to technical changes; no liability accepted for the accuracy of the information given. See General Terms and Conditions in footer for additional details.
